Description
The Yale 3000 Series J3501 is an architectural surface-mounted door closer designed for commercial and institutional buildings. Its cast aluminum body, rack and pinion mechanism, and adjustable spring sizes (1-6) provide reliable, smooth door closing for virtually any application, from high-traffic entries to low-energy requirements.
This non-handed closer accommodates regular arm, top jamb, and parallel arm mounting options. Separate valves control latch, sweep, and backcheck intensity independently for precise operation. Verify compatibility with your door size and weight before ordering. As an authorized Yale dealer, E.D. Locks offers expert selection guidance and support at sales@edlocks.com or 1-877-207-6067 to ensure proper installation and performance.
Specifications
- Cast aluminum body
- Adjustable spring sizes 1 through 6
- Tri-packed: regular arm, top jamb, and parallel arm mounting
- Non-handed
- Staked valves
- Rack and pinion design
- 1-1/4 inch (32mm) diameter piston
- 5/8 inch (16mm) diameter pinion journals
- Separate and independent latch, sweep, and backcheck intensity valves
- 2-1/8 inch (54mm) projection (standard covers)
