Description
Yale's 3000 Series J3301 is an architectural surface-mounted door closer engineered for reliable, controlled door closing in commercial and institutional buildings. Its rack and pinion design, adjustable spring sizes, and independent valve controls solve the challenge of finding a durable closer that handles diverse traffic patterns and mounting configurations without sacrificing appearance.
The J3301 is non-handed and tri-packed for regular arm, top jamb, and parallel arm mounting flexibility. It features staked valves, self-drilling screws, and Yale's full range of commercial finishes. As an authorized E.D. Locks dealer, we provide expert guidance on sizing, finish selection, and installation. Contact sales@edlocks.com or call 1-877-207-6067 for personalized support and fast shipping.
Specifications
- Cast aluminum body
- Adjustable spring sizes: 1 through 6
- 1-1/4" (32mm) diameter piston
- 5/8" (16mm) diameter pinion journals
- 2-1/8" (54mm) projection (standard covers)
- Separate and independent latch, sweep, and backcheck intensity valves
- Rack and pinion design
- Staked valves
- Non-handed
- Tri-packed mounting options
