Description
The Yale 3000 Series J3511 is a commercial-grade surface-mounted door closer designed for high-traffic interior and exterior doors in offices, schools, hospitals, and other institutional facilities. Its cast aluminum body, rack-and-pinion mechanism, and independent valve controls solve the challenge of achieving reliable, adjustable door closing performance in demanding environments.
This closer accommodates adjustable spring sizes 1-6 and ships tri-packed with regular arm, top jamb, and parallel arm mounting options, making it non-handed and suitable for most standard door frames. For expert advice on selecting the right closer for your application, sizing, or finishing options, contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067.
Specifications
- Cast aluminum body
- Rack and pinion design
- Adjustable spring sizes 1 through 6
- 1-1/4" (32mm) diameter piston
- 5/8" (16mm) diameter pinion journals
- Separate and independent latch, sweep, and backcheck intensity valves
- Staked valves
- Non-handed mounting
- 2-1/8" (54mm) projection (standard covers)
- Tri-packed: regular arm, top jamb, and parallel arm options
- Self-drilling and tapping screws included
