Description
The Yale 3000 Series J3511 is an architectural surface-mounted door closer designed for commercial and institutional buildings requiring reliable, durable performance. It solves the need for hands-free door closing with adjustable control, serving properties that demand both functionality and professional appearance across diverse entry scenarios.
Compatible with standard door frames using regular arm, top jamb, or parallel arm mounting options, this non-handed closer accepts adjustable spring sizes 1-6 to match your door weight and traffic pattern. As an authorized Yale dealer, E.D. Locks provides expert guidance on selection, finish options, and installation support. Contact sales@edlocks.com or call 1-877-207-6067 for assistance.
Specifications
- Brand: Yale/Accentra
- Model: J3511
- Projection: 0-3/8 inch (standard covers)
- Body: Cast aluminum
- Spring Sizes: Adjustable 1-6
- Piston Diameter: 1-1/4 inch (32mm)
- Pinion Journals: 5/8 inch (16mm) diameter
- Design: Rack and pinion with staked valves
- Valve Control: Separate latch, sweep, and backcheck intensity adjustment
- Mounting: Non-handed; regular arm, top jamb, or parallel arm options
- Hardware: Self-drilling and tapping screws included
