Description
The Yale 8800 Series VIR8805FL mortise lock delivers ANSI/BHMA Grade 1 strength for commercial doors requiring maximum security and durability. This heavy-duty lock features a reinforced stainless steel deadbolt, vandal-resistant trim, and field-reversible handing that simplifies installation on 1-3/4" standard doors and thicker applications.
Compatible with standard 2-3/4" backset installations, this lock arrives keyed-random with two brass keys and accepts optional 7-pin cylinders. UL/cUL fire-rated for up to 3 hours, it's backed by Yale's 10-year mechanical warranty. Contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067 for expert guidance on keying, handing, and finish selection.
Specifications
- Certification: ANSI/BHMA A156.13, Series 1000, Operational Grade 1
- Fire Rating: UL/cUL fire rated up to 3 hours
- Mechanism: Stainless steel
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door Thickness: 1-3/4" standard, to 3-1/4" thick doors to order
- Cylinders: Brass, 6-pin keyed-random with two keys standard; 7-pin available
- Reversibility: Field reversible handing
- Strike: 1-1/4" curved lip for 1-3/4" door standard; other sizes to special order
- Finishes: 17 finishes available
- Warranty: 10 year mechanical
