Description
The Yale 8800 Series mortise lock is engineered for commercial applications demanding uncompromising strength and durability. This Grade 1 certified lock features a reinforced stainless steel deadbolt, heavy-duty vandal-resistant trim, and field-reversible design that simplifies installation and handing on the job site.
Compatible with standard 1-3/4" doors and adjustable up to 3-1/4" thick doors. Includes 2-3/4" backset, 6-pin keyed-random cylinder with two keys, and reversible strike. As an authorized Yale dealer, E.D. Locks provides expert guidance on finish selection, keying options, and installation support. Contact sales@edlocks.com or call 1-877-207-6067 for technical assistance.
Specifications
- ANSI/BHMA Certification: Grade 1, Series 1000
- Fire Rating: UL/cUL rated up to 3 hours
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door Thickness: 1-3/4" standard; up to 3-1/4" to order
- Front: Bevel front, free-floating (flat to 1/8" standard bevel)
- Cylinder: Brass, 6-pin, keyed-random with 2 keys standard; 7-pin available
- Strike: 1-1/4" curved lip for 1-3/4" door standard; other lengths to order
- Finishes: 17 available
- Warranty: 10 years mechanical
- Field Reversible: Yes
