Description
The Yale 8800 Series mortise lock is engineered for commercial doors demanding maximum strength and security. This trim pack suits facility managers, building owners, and security professionals who need ANSI/BHMA Grade 1 certified hardware rated for high-traffic entrances, stairwells, and secure areas. Its reinforced stainless steel deadbolt and vandal-resistant trim solve durability concerns in demanding environments.
The VIR8809FL fits standard 1-3/4" door thickness with field-reversible handing and a 2-3/4" backset, simplifying installation and future adjustments. An authorized E.D. Locks dealer ensures expert guidance on finish selection from 17 commercial options, cylinder specifications, and strike compatibility. Contact sales@edlocks.com or call 1-877-207-6067 for technical support and to confirm your door and keying requirements.
Specifications
- ANSI/BHMA Grade 1 certified, A156.13 Series 1000
- UL/cUL fire rated up to 3 hours
- Windstorm certified
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door thickness: 1-3/4" standard, to 3-1/4" available
- Mechanism: Stainless steel
- Front: Bevel front, free-floating (flat to 1/8" bevel)
- Cylinders: Brass, 6-pin keyed-random, two keys standard
- Field reversible handing
- Strikes: 1-1/4" curved lip for 1-3/4" door (standard)
- Finishes: 17 commercial options
- Warranty: 10 years mechanical
