Description
The Yale 8800 Series mortise lock is a commercial-grade entry solution for offices, institutions and facilities demanding ANSI/BHMA Grade 1 durability. This trim pack includes heavy-duty vandal-resistant hardware, a reinforced stainless steel deadbolt, and field-reversible components that simplify installation on doors 1-3/4" to 3-1/4" thick.
The VIR8812-2FL 626 is UL/cUL fire-rated for up to 3 hours and ships with a 6-pin keyed-random cylinder and two keys. Fits standard 2-3/4" backset applications with 3/4" stainless steel latchbolt throw. Contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067 for finish selection, keying options, and professional guidance on your commercial door security project.
Specifications
- ANSI/BHMA Certification: A156.13, Series 1000, Operational Grade 1
- Fire Rating: UL/cUL rated up to 3 hours
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door Thickness: 1-3/4" standard, to 3-1/4" thick doors to order
- Mechanism: Stainless steel
- Cylinder: Brass, 6-pin, keyed-random with two keys standard (7-pin available)
- Strike: 1-1/4" curved lip for 1-3/4" door standard; reversible
- Reversibility: Field reversible handing
- Finishes: 17 available finishes
- Warranty: 10 year mechanical
