Description
The Falcon W581PD LAT 622 is an affordable cylindrical lock designed for lower-traffic commercial doorways in government, retail, industrial, and multi-family buildings. It features a conventional cylinder with removable components for easy re-keying, non-handed operation, and compatibility with standard 6-pin cylinders from Falcon, Schlage, Corbin-Russwin, Yale, and Sargent. Heavy wrought brass or bronze roses and pressure-cast zinc levers ensure durability and aesthetic consistency across door hardware.
This lock fits standard door thicknesses from 1-3/8 to 1-3/4 inches with 2-3/4 inch backset (2-3/8 inch also available). As an authorized E.D. Locks dealer, we provide expert guidance on cylinder keying options, master keying across Falcon and Schlage C keyways, and product selection. Contact our sales team at sales@edlocks.com or 1-877-207-6067 for installation support and to discuss interchangeable core options.
Specifications
- Door Thickness: 1-3/8 inch to 1-3/4 inch standard
- Backset: 2-3/4 inch standard; 2-3/8 inch also available
- Cylinder: Six-chamber conventional pinning, removable for re-keying
- Bolt Projection: 1/2 inch, stainless steel, UL listed for 3-hour door assemblies
- Latch Face: 1 inch x 2-1/4 inch (2-3/8 inch backset) or 1-1/8 inch x 2-1/4 inch (2-3/4 inch backset)
- Strike: 4-7/8 inch x 1-1/4 inch ANSI with curved lip
- Finish: 622
- Handing: Non-handed
- Keyway: G keyway standard; optional keyways available
- Keys: Two nickel silver keys included
