Description
The Securitron WEMB-CL-48 is an electromechanical request-to-exit device designed for magnetically locked doors and delayed egress systems. Its mechanical push bar requires no special tools or knowledge to operate, meeting code requirements for emergency egress. The low-profile design activates with just 1/4" of movement and can be field-cut up to 48" wide to fit non-standard openings.
This all-metal exit bar features redundant DPDT switches for fault-tolerant, reliable operation and includes 16 ft. of 22AWG cable with armored door cord. Compatible with Securitron's standard mounting pattern and direct retrofit for select competitor footprints. Optional waterproof switches support outdoor protected applications. Contact E.D. Locks at sales@edlocks.com or 1-877-207-6067 for compatibility verification and expert installation guidance as an authorized Securitron dealer.
Specifications
- Brand: Securitron
- Model: WEMB-CL-48
- Product Type: Electromechanical Exit Bar
- Maximum Width: 48 inches (field-cuttable)
- Activation Movement: 1/4 inch
- Switch Type: DPDT (Dual Pole Dual Throw)
- Switch Rating: 5A
- Cable Length: 16 feet
- Cable Gauge: 22AWG, 6 conductor
- Construction: All metal
- Included: Armored door cord
