Description
The Sargent 80 Series exit device is a Grade 1 panic bar designed for metal doors in commercial and institutional buildings. This rim-mounted solution provides durable egress hardware that exceeds ANSI/BHMA standards, with modular construction and minimal maintenance requirements. Ideal for facilities prioritizing security and code compliance.
This right-hand reverse (RHR) device works with metal doors 1.75 inches to 2.25 inches thick and door widths from 24 to 48 inches using interchangeable rail sizes. Compatible with standard 650 top and 606 bottom strikes. Contact an authorized E.D. Locks specialist at sales@edlocks.com or 1-877-207-6067 for assistance selecting rail size, electric options (alarm, photoluminescent, delayed egress, remote latch retraction), and keying configuration.
Specifications
- Series: Sargent 80 Series
- Model: AD8610F RHR 10BE
- Configuration: Rim with Hex Key Dogging
- Grade: ANSI/BHMA Grade 1
- Door Thickness: 1.75 to 2.25 inches
- Door Width Range: 24 to 48 inches
- Device Centerline Height: 41 inches (standard), 38 inches (accessible)
- Rail Options: E (24-32in), F (33-36in), J (37-42in), G (43-48in)
- Strikes: 650 Top, 606 Bottom (panic and fire-rated)
- Pushbar Projection: 3 inches (neutral), 2.125 inches (depressed)
- Top Bolt: Stainless steel
- Center Case: 8.375 x 2.625 inches
- Maximum Door Height: 96 inches
