Description
The Sargent 80 Series exit device is a heavy-duty panic bar solution for facilities requiring Grade 1 security and reliability throughout the building's lifetime. Ideal for metal doors in commercial, institutional and industrial settings, this rim-mounted device delivers ANSI/BHMA Grade 1 performance with modular construction, minimal moving parts and maintenance-free operation that protects occupants and assets alike.
This LHR (left-hand reverse) unit suits door widths 24-36 inches and installs on 1.75-inch minimum thickness metal doors. Compatible with optional delayed egress, alarmed exit and electric latch retraction features for specialized applications. As an authorized Sargent dealer, E.D. Locks provides expert configuration assistance and fast shipping. Contact sales@edlocks.com or 1-877-207-6067 for sizing, keying and specification help.
Specifications
- Brand: Sargent
- Model: 19-AD8646F LHR 10BE
- Configuration: Rim exit device
- Door Type: Metal, 1.75 inch (44mm) minimum thickness
- Door Width Range: 24-36 inches (E Rail, factory cut to size)
- Device Centerline: 41 inches (1041mm) from finished floor
- Center Case Dimensions: 8.375 x 2.625 inches (213 x 67mm)
- Pushbar Projection Neutral: 3 inches (76mm)
- Pushbar Projection Depressed: 2.125 inches (54mm)
- Top Bolt: Stainless steel
- Strike: 650 Top and 606 Bottom (panic and fire rated)
- Dogging: Hex key standard (non fire-rated)
- Rating: ANSI/BHMA Grade 1
- Maximum Door Height: 96 inches
