Description
The Sargent 80 Series AD8646F is a heavy-duty rim exit device engineered for metal doors in high-traffic commercial and institutional buildings. Built to exceed ANSI/BHMA Grade 1 standards, it delivers reliable emergency egress with minimal maintenance, making it ideal for facilities demanding durability and security throughout the building's lifecycle.
This left-hand reverse model fits 1-3/4" minimum thickness metal doors and includes a 650 top strike and 606 bottom strike (panic and fire-rated). Rails are available in four sizes keyed to door width (E, F, J, G rails for 24-48" openings). An authorized E.D. Locks dealer can help you select the correct rail size, verify door specifications, and configure optional features like delayed egress, alarming, or electric latch retraction. Contact sales@edlocks.com or 1-877-207-6067 for expert guidance.
Specifications
- Brand: Sargent
- Model: AD8646F LHR 10BE
- Configuration: Rim, Left Hand Reverse
- Door Types: Metal doors, 1-3/4" (44mm) minimum thickness; up to 2-1/4" thick with specification
- Minimum Stile Width: 4-1/2" (114mm)
- Device Centerline Height: 41" (1041mm) standard; 38" (965mm) for elementary schools
- Maximum Door Opening Height: 96"
- Maximum Door Opening: 120" (3048mm)
- Center Case Dimensions: 8-3/8" (213mm) x 2-5/8" (67mm)
- Pushbar Projection: 3" (76mm) neutral, 2-1/8" (54mm) depressed
- Top Bolt: Stainless steel
- Strike Included: 650 top strike and 606 bottom strike (panic and fire-rated)
- Dogging: Hex key dogging standard (non fire-rated); cylinder dogging available
- Fasteners: Machine screws supplied standard
- Standards Compliance: Exceeds ANSI/BHMA Grade 1 for cycle and strength
