Description
The Sargent 80 Series exit device is a heavy-duty panic hardware solution designed for commercial buildings requiring ANSI/BHMA Grade 1 security and durability. This left-hand reverse model with 10BE finish is ideal for metal doors 1 3/4 inches or thicker, offering rim configuration with modular construction and minimal moving parts for maintenance-free operation.
This device ships with stainless steel top bolt and standard machine screw fasteners, pre-sized for 41 inches centerline from finished floor. Compatible with E, F, J, or G rails depending on door width (24 to 48 inches). Contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067 for rail selection, electric option compatibility, and detailed installation support.
Specifications
- Model: 1956-AD8606F LHR 10BE
- Series: Sargent 80
- Configuration: Rim, Left-Hand Reverse
- Door Thickness: 1 3/4 inches minimum; up to 2 1/4 inches with specification
- Minimum Stile Width: 4 1/2 inches
- Rail Options: E (24-32 inches), F (33-36 inches), J (37-42 inches), G (43-48 inches)
- Maximum Door Height: 120 inches
- Device Centerline: 41 inches from finished floor (38 inches for elementary schools)
- Center Case Dimensions: 8 3/8 inches x 2 5/8 inches
- Pushbar Projection: 3 inches neutral, 2 1/8 inches depressed
- Top Bolt: Stainless steel
- Strike: 650 Top Strike and 606 Bottom Strike
- Dogging: Hex key standard (cylinder dogging available)
