Description
The Sargent 80 Series exit device is a heavy-duty panic hardware solution designed for commercial buildings, schools, and facilities requiring Grade 1 security and durability. This rim-mounted device exceeds ANSI/BHMA standards, features modular construction with minimal moving parts, and delivers maintenance-free operation throughout the building's life.
Compatible with metal doors 1 3/4" to 2 1/4" thick, the 55-AD8606F is available with four rail sizes (E, F, J, G) to fit door widths from 24" to 48". Optional electric features include delayed egress, alarms, photoluminescent coating, and remote latch retraction. Contact E.D. Locks at sales@edlocks.com or 1-877-207-6067 for expert guidance on configuration, keying, and installation support as an authorized dealer.
Specifications
- Model: 55-AD8606F LHR 10BE
- Brand: Sargent
- Series: 80 Series
- Configuration: Rim Mount
- Door Thickness: 1 3/4" to 2 1/4" (44mm to 57mm)
- Minimum Stile Width: 4 1/2" (114mm)
- Device Centerline: 41" (1041mm) from finished floor; 38" (965mm) for elementary schools
- Maximum Door Height: 96"
- Maximum Door Opening: 120" (3048mm)
- Center Case: 8 3/8" (213mm) x 2 5/8" (67mm)
- Pushbar Projection (Neutral): 3" (76mm)
- Pushbar Projection (Depressed): 2 1/8" (54mm)
- Top Bolt: Stainless Steel
- Strike: 650 Top Strike and 606 Bottom Strike (panic and fire-rated)
- Rail Sizes: E (24-32"), F (33-36"), J (37-42"), G (43-48")
- Dogging: Hex key standard; cylinder dogging available (specify 16-)
- Standards: Exceeds ANSI/BHMA Grade 1
