Description
The Sargent 80 Series exit device is a heavy-duty panic bar solution for commercial metal doors requiring ANSI/BHMA Grade 1 certified security. Built with modular construction and minimal moving parts, this LHR (left-hand reverse) rim-mounted device suits facilities prioritizing durability, low maintenance, and reliable egress control across their building lifecycle.
This device fits metal doors 1.75 inches minimum thickness and accommodates door widths 24 to 48 inches via four interchangeable rail sizes (E, F, J, G). Optional electric features include delayed egress, alarm, photoluminescent coating, and latch monitoring. As an authorized Sargent dealer, E.D. Locks provides expert specification and installation support at sales@edlocks.com or 1-877-207-6067.
Specifications
- Brand: Sargent
- Model: 1956-MD8643F LHR 20D
- Configuration: Rim-mounted, left-hand reverse
- Door Type: Metal, 1.75 inch minimum thickness
- Door Width Range: 24 to 48 inches (rail-dependent)
- Rail Options: E (24-32 inch), F (33-36 inch), J (37-42 inch), G (43-48 inch)
- Strike Type: 650 Top and 606 Bottom (panic and fire-rated)
- Dogging: Hex key standard (non-fire-rated); cylinder dogging available
- Device Centerline Height: 41 inches (standard), 38 inches (ADA with auxiliary control)
- Center Case Dimensions: 8.375 inch W x 2.625 inch H
- Pushbar Projection: 3 inches (neutral), 2.125 inches (depressed)
- Top Bolt: Stainless steel
- Fasteners: Machine screws supplied
- Certifications: Exceeds ANSI/BHMA Grade 1
- Optional Electric Features: Alarm, beacon, photoluminescent coating, illuminated touchpad, latchbolt monitor, outside lever monitoring, request-to-exit signal, remote latch retraction, delayed egress, electric dogging, electroguard self-contained delayed egress
