Description
The Sargent 80 Series exit device is a Grade 1 panic hardware solution for metal doors in commercial and institutional buildings. Ideal for facilities requiring durable, maintenance-free security, this rim-mounted device exceeds ANSI/BHMA standards and suits doors 1 3/4 inches to 2 1/4 inches thick with modular construction and minimal moving parts.
This left-hand reverse model fits door widths 24 to 48 inches using factory-cut rails (E, F, J, or G sizes). Compatible with 650 top and 606 bottom strikes for fire-rated applications. For proper sizing, rail selection, and electric option setup (alarm, photoluminescent, delayed egress, latch monitoring, or dogging), contact an authorized Sargent dealer at sales@edlocks.com or 1-877-207-6067 for expert guidance.
Specifications
- Brand: Sargent
- Series: 80
- Model: 1956-MD8613F
- Configuration: Rim, Left-Hand Reverse, 20D
- Door Thickness: 1 3/4 inch to 2 1/4 inch minimum
- Door Width Range: 24 to 48 inches
- Rail Options: E (24-32), F (33-36), J (37-42), G (43-48)
- Stile Width: 4 1/2 inch minimum
- Standard Dogging: Hex key (non fire-rated)
- Top Bolt: Stainless steel
- Device Centerline: 41 inches standard, 38 inches for accessible applications
- Maximum Door Height: 96 inches
- Center Case Dimensions: 8 3/8 inches x 2 5/8 inches
- Pushbar Projection: 3 inches neutral, 2 1/8 inches depressed
- Strikes: 650 top, 606 bottom (fire-rated)
- Fasteners: Machine screws supplied
- Certifications: ANSI/BHMA Grade 1
