Description
The Sargent 6500 Series is a standard-duty key-in-lever lock that meets ANSI A156.2 Series 4000 Grade 2 requirements. Designed for interior and exterior doors 1-3/8" to 1-3/4" thick, this universal-hand lock provides reliable security and easy operation for commercial and institutional facilities.
This lock features a 2-3/4" backset, steel zinc dichromate cylindrical housing, and a brass 1/2" throw latch with two nickel silver keys. It installs on ANSI A115.2 (161) modified bore patterns with a 4-1/2" minimum stile. Contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067 for keying options, strike compatibility, and installation support.
Specifications
- Brand: Sargent
- Model: 28-65G05 KP 26
- Door Thickness: 1-3/8" to 1-3/4" (35mm to 44mm)
- Backset: 2-3/4" standard (70mm); 2-3/8" optional (60mm)
- Cylindrical Housing: Steel zinc dichromate finish
- Front: Wrought brass and stainless steel, 2-1/4" x 1-1/8"
- Latch: Brass, 1/2" throw
- Keys: Two, nickel silver
- Cylinder: Brass, 6-pin, LA keyway standard
- Hand: Universal
- Strike Options: 600 Curved Lip (brass or stainless steel standard), 808 ANSI Curved Lip, 505 Full Lip
- Door Prep: ANSI A115.2 (161) Modified
- Minimum Stile: 4-1/2"
- Grade: ANSI A156.2 Series 4000 Grade 2
