Description
The Sargent 6500 Series 28-65U15 KP is a standard-duty key-in-lever lock engineered for commercial and institutional doors. Exceeding ANSI A156.2 Series 4000 Grade 2 requirements, this universal-hand lock accommodates door thicknesses from 1-3/8" to 1-3/4" and delivers reliable keyed access control with a 1/2" throw latch.
Compatible with ANSI A115.2 (161) modified door prep, this lock installs on doors with minimum 4-1/2" stiles and includes two nickel silver keys and a brass 6-pin LA keyway cylinder. E.D. Locks is an authorized Sargent dealer offering expert technical support at sales@edlocks.com or 1-877-207-6067 to ensure correct specification and installation for your application.
Specifications
- Brand: Sargent
- Model: 28-65U15 KP 4
- Grade: ANSI A156.2 Series 4000 Grade 2
- Lock Type: Key-in-Lever, Standard Duty
- Door Thickness: 1-3/8" to 1-3/4" (35mm to 44mm)
- Backset: 2-3/4" (70mm) standard; 2-3/8" (60mm) optional
- Hand: Universal, not handed
- Latch Throw: 1/2" (13mm)
- Cylinder: Brass, 6-pin, LA keyway
- Keys Included: Two nickel silver
- Front Plate: Wrought brass and stainless steel, 2-1/4" x 1-1/8"
- Housing: Steel zinc dichromate finish
- Strike Options: 600 Curved Lip (brass or stainless), 808 ANSI Curved Lip, 505 Full Lip
- Available Finishes: 3, 4, 10, 10B, 26, 26D
- Door Prep: ANSI A115.2 (161) Modified
- Minimum Stile Width: 4-1/2" (114mm)
