Description
The LCN 4040XP-30 633 is a heavy-duty door closer engineered for high-traffic institutional and commercial environments. It delivers 44% increased bearing load capacity, the strongest pinion at 3/4" journal diameter, and the widest bearing at 5/8". The V-Shield seal extends life 20% longer, making it ideal for facilities demanding maximum durability and reliability.
This non-handed closer mounts on hinge side, top jamb, or parallel arm and accommodates interior doors to 5'0" and exterior doors to 4'0". UL and cUL listed to ANSI A156.4 grade one, it features fast power adjust for quick installation. Contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067 for expert guidance on finish options, corrosion protection, and accessory compatibility.
Specifications
- Brand: LCN
- Model: 4040XP-30 633
- Bearing Load: 44% increased capacity
- Pinion Journal Diameter: 3/4"
- Bearing Width: 5/8"
- Seal: V-Shield with 20% longer life
- Interior Door Range: Up to 5'0"
- Exterior Door Range: Up to 4'0"
- Non-Handed: Yes
- Mount Options: Hinge side, top jamb, parallel arm
- Certifications: UL, cUL, ANSI A156.4 Grade One
- Material: Cast iron, forged steel arm, double heat-treated steel pinion
- Fluid: All weather
- Finish Options: Standard powder coat, optional plated finish, optional SRI primer
- Fast Power Adjust: Yes
