Description
The LCN 4040XP-79 633 is a heavy duty institutional door closer built for high traffic facilities and demanding applications. It features 44% increased bearing load capacity, a reinforced 3/4" pinion journal, and an enhanced V-shield seal for superior durability. Non-handed design fits interior doors up to 5'0" and exterior doors up to 4'0", solving the need for reliable, long-lasting door control in schools, hospitals, and commercial buildings.
This closer mounts on the hinge side, top jamb, or with optional parallel arm bracket on either right or left swinging doors. It is UL and cUL listed per ANSI A156.4 grade one, and available with standard or custom powder coat finish, optional plating, or SRI primer for corrosive environments. Contact E.D. Locks at sales@edlocks.com or 1-877-207-6067 for expert guidance on sizing, finish selection, and installation support as an authorized LCN dealer.
Specifications
- Brand: LCN
- Model: 4040XP-79 633
- Type: Heavy Duty Door Closer
- Bearing Load Capacity: 44% increase over standard
- Pinion Journal: 3/4" diameter
- Bearing Width: 5/8"
- Interior Door Range: up to 5'0"
- Exterior Door Range: up to 4'0"
- Seal: V-shield with 20% longer life
- Material: Cast iron body, forged steel arm, double heat treated steel pinion
- Fluid: All weather
- Handed: Non-handed
- Mounting Options: Hinge side, top jamb, parallel arm (with PA bracket)
- Finish Options: Standard powder coat, custom powder coat, optional plating, optional SRI primer
- Certifications: UL and cUL listed, ANSI A156.4 Grade One
- Compatible Accessories: All 4040 series accessories
