Description
The LCN 4040XP-419 is a heavy-duty institutional door closer built for high-traffic, demanding environments. It features 44% increased bearing load capacity, the strongest pinion ever at 3/4" journal diameter, and LCN's V-shield seal with 20% longer life. Ideal for schools, hospitals, and commercial buildings requiring reliable performance.
This non-handed closer mounts on the hinge side, top jamb, or with a parallel arm bracket, and adjusts for interior doors to 5'0" and exterior doors to 4'0". It meets ADA requirements and is UL/cUL listed to ANSI A156.4 grade one. Contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067 for expert sizing, finish options, and installation guidance.
Specifications
- Brand: LCN
- Model: 4040XP-419
- Finish Code: US26D
- Pinion Journal Diameter: 3/4"
- Bearing Width: 5/8"
- Interior Door Range: up to 5'0"
- Exterior Door Range: up to 4'0"
- Mounting: Hinge side, top jamb, or parallel arm
- Handed: Non-handed
- Certifications: UL, cUL, ANSI A156.4 Grade One
- Material: Cast iron body, forged steel arm, double heat-treated steel pinion
- Fluid: All-weather
- Features: V-shield seal, fast power adjust, fast and accurate installation
