Description
The LCN 4040XP-72MC RH is a heavy-duty institutional door closer built for demanding, high-traffic applications. It features 44% increased bearing load capacity, the strongest pinion ever at 3/4" journal diameter, and a V-shield seal with 20% longer life. Ideal for facilities requiring maximum durability and reliability.
This non-handed closer mounts on either right or left swinging doors via hinge side, top jamb, or parallel arm bracket. It adjusts for interior doors to 5'0" and exterior doors to 4'0", and meets ADA requirements. UL and cUL listed, it's tested to ANSI A156.4 grade one. As an authorized LCN dealer, ED Locks offers expert guidance on sizing, finishes, and installation. Contact our sales team at sales@edlocks.com or 1-877-207-6067 for assistance.
Specifications
- Brand: LCN
- Model: 4040XP-72MC RH
- Bearing Load Capacity: 44% increased
- Pinion Journal Diameter: 3/4"
- Bearing Width: 5/8"
- Material: Cast Iron, Forged Steel Arm, Double Heat Treated Steel Pinion
- Seal: V-shield with 20% longer life
- Fluid: All Weather
- Handing: Non-Handed
- Interior Door Range: Up to 5'0"
- Exterior Door Range: Up to 4'0"
- Mounting: Hinge side, top jamb, or parallel arm (with PA bracket)
- Certifications: UL and cUL Listed, ANSI A156.4 Grade One
- Finish Options: Standard or optional custom powder coat, optional plated finish on metal cover/arm/fasteners, optional SRI primer for corrosive environments
- ADA Compliant: Yes
