Description
The Sargent 80 Series exit device is a Grade 1 panic hardware solution for metal doors in commercial and institutional buildings. Ideal for facilities requiring durable, maintenance-free security, this rim-mounted device features modular construction and exceeds ANSI/BHMA strength and cycle requirements. Available with optional delayed egress, alarm, and electric latch retraction for specialized applications.
This unit mounts on 1-3/4" minimum thickness doors with rails available for 24" to 48" door widths (factory-cut to your specifications). Compatible with 650 top and 606 bottom strikes. As an authorized Sargent dealer, E.D. Locks provides expert guidance on configuration, keying, and electric options. Contact sales@edlocks.com or 1-877-207-6067 for technical assistance and free shipping on orders over $450.
Specifications
- Model: 55-AD8613F LHR 10BE
- Series: Sargent 80
- Grade: ANSI/BHMA Grade 1
- Door Thickness: 1-3/4" (44mm) minimum
- Minimum Stile Width: 4-1/2" (114mm)
- Device Centerline: 41" (1041mm) from finished floor
- Center Case Dimensions: 8-3/8" x 2-5/8"
- Pushbar Projection (Neutral): 3" (76mm)
- Pushbar Projection (Depressed): 2-1/8" (54mm)
- Maximum Door Height: 96"
- Maximum Door Opening Height: 120" (3048mm)
- Top Bolt: Stainless steel
- Strikes: 650 Top Strike and 606 Bottom Strike
- Dogging: Hex key standard (cylinder dogging available)
