Description
The Adams Rite 8222LR-48 is an electric latch retraction exit device designed for narrow stile aluminum doors up to 48 inches wide. Built for high-traffic commercial entrances, it combines a durable extruded aluminum pushbar with reliable electric latch retraction to meet ADA and life safety codes while providing convenient egress control.
This non-handed device fits standard 1-3/4" to 2-1/4" door thickness and adjusts from 30" to 44" bar height for doors up to 8 feet tall. For compatibility questions, door preparation, cylinder selection, or keying assistance, contact E.D. Locks' expert team at sales@edlocks.com or 1-877-207-6067. As an authorized dealer, we provide pre-sale guidance to ensure correct specification and seamless installation.
Specifications
- Brand: Adams Rite
- Model: 8222LR-48
- Function: Electric Latch Retraction
- Pushbar Length: 48 inches
- Bar Height Adjustment: 30 inch to 44 inch
- Door Height Capacity: Up to 8 feet (10 feet with optional 8055 Tall Door Kit)
- Door Thickness: 1-3/4 inch to 2-1/4 inch
- Minimum Stile Width: 3-3/4 inch
- Projection: 2-15/16 inch fully projected, 1-15/16 inch dogged
- Material: Extruded aluminum pushbar
- Finish: Dark Bronze
- Handing: Non-handed, field reversible
- Dogging: Standard hex key dogging
- Door Type: Narrow stile aluminum
- Warranty: Five year limited
