Description
The Adams Rite 8312C-7136 is a mortise exit device designed for hollow metal and wood doors in commercial and institutional buildings. This non-handed device features a 36-inch aluminum pushbar with cylinder dogging, adjustable bar height from 30 to 44 inches, and suits standard 1-3/4-inch door thickness up to 8 feet tall. It solves the need for reliable, code-compliant emergency egress on high-traffic doors.
Compatible with doors up to 2-1/4-inch thick and featuring field-reversible lever entry trim, the 8312C-7136 accepts standard rim cylinders and optional mortise cylinders (sold separately). Installation uses self-tapping screws or optional sex bolt kits. As an authorized Adams Rite dealer, E.D. Locks provides expert sizing and installation guidance at sales@edlocks.com or 1-877-207-6067, plus free shipping on orders over $450.
Specifications
- Brand: Adams Rite
- Model: 8312C-7136
- Type: Mortise Exit Device with Cylinder Dogging
- Pushbar Length: 36 inches
- Bar Height Range: 30 to 44 inches
- Door Height Capacity: Up to 8 feet (standard)
- Door Thickness: 1-3/4 inches standard, suits up to 2-1/4 inches
- Minimum Stile Width: 3-7/8 inches
- Projection: 2-15/16 inches (extended), 1-15/16 inches (dogged)
- Material: Extruded aluminum pushbar
- Handing: Non-handed, field-reversible trim
- Door Types: Hollow metal and wood
- Fastening: Self-tapping screws or sex bolt kits (optional)
- Cylinder: Accepts standard rim cylinders or mortise cylinders with MS cam (1 inch to 1-1/4 inch lengths)
- Warranty: Five-year limited
