Description
The HES 9500 Series is a surface-mounted electric strike engineered for rim exit devices with 3/4" Pullman latches. Its 3/4" thick stainless steel housing completely encase all components, eliminating frame cutting during installation. Ideal for commercial doors requiring fire-rated security without costly structural modifications, this Grade 1 strike solves retrofit challenges in existing openings.
Field-selectable for fail-secure or fail-safe operation at 12 or 24VDC, the 9500 meets UL 10C (3-hour), NFPA 80-07, and ANSI/BHMA A156.31 standards. Verify compatibility with your exit device before ordering. As an authorized HES dealer, E.D. Locks provides expert configuration guidance: call 1-877-207-6067 or email sales@edlocks.com for free assistance selecting the right voltage and fail mode for your application.
Specifications
- Fire Rating: UL 10C, 3-hour (fail secure)
- Housing: 3/4" thick stainless steel, surface-mounted
- Latch Compatibility: Rim exit devices, 3/4" Pullman latch
- Voltage: Field-selectable 12 or 24VDC
- Operation: Field-selectable fail-secure or fail-safe
- Grade: ANSI/BHMA A156.31 Grade 1
- Standards: UL 10C, UL 1034, UL 294 (6th Ed.), NFPA 80-07, NFPA-252, CAN4-S104 (ULC-S104), ASTM-E152
- Listings: California Fire Marshall, WHI fire door, burglary-resistant (UL 1034), outdoor suitable
- Compliance: RoHS compliant
- Patents: #6,390,520
