Description
The Yale 8847FL 626 Trim Pack is a commercial-grade mortise lock assembly designed for doors requiring ANSI/BHMA Grade 1 security and durability. Built with reinforced stainless steel components and vandal-resistant trim, it suits office buildings, institutional facilities, and high-traffic commercial spaces where reliable access control is essential.
This trim pack fits standard 1-3/4" doors and features field-reversible handing for flexible installation. The lock is UL/cUL fire-rated up to 3 hours and includes a 6-pin cylinder with two keys. For assistance selecting the right finish (17 available) or verifying compatibility with your door thickness, contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067 for expert guidance.
Specifications
- Certification: ANSI/BHMA A156.13 Series 1000, Grade 1
- Fire Rating: UL/cUL up to 3 hours
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door Thickness: 1-3/4" standard (custom up to 3-1/4")
- Cylinder: Brass, 6-pin keyed-random with 2 keys included
- Strike: 1-1/4" curved lip (reversible)
- Handing: Field reversible
- Warranty: 10 years mechanical
- Finishes: 17 options available
