Description
The Yale 8800 Series mortise lock trim pack is engineered for commercial doors demanding ANSI Grade 1 security and durability. This complete trim assembly suits facility managers, integrators, and property owners protecting high-traffic entries with reinforced stainless steel components, field-reversible handing, and heavy-duty vandal-resistant construction.
Compatible with standard 1-3/4" doors and adjustable to 3-1/4" thick doors by special order. Keying is random with two brass keys standard; 7-pin cylinders available. As an authorized Yale dealer, E.D. Locks provides expert guidance on finish selection, installation, and keying options. Contact sales@edlocks.com or call 1-877-207-6067 for personalized support and fast shipping.
Specifications
- ANSI/BHMA Certification: A156.13 Series 1000, Grade 1
- UL/cUL Fire Rating: Up to 3 hours
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door Thickness: 1-3/4" standard (up to 3-1/4" special order)
- Front: Bevel, free-floating 1/8" to standard adjustment
- Cylinders: Brass 6-pin keyed-random, two keys (7-pin available)
- Reversibility: Field-reversible handing
- Strike: 1-1/4" curved lip, reversible (other lengths special order)
- Finishes: 17 available
- Warranty: 10 years mechanical
