Description
The Corbin Russwin DL2211 is a Grade 2 certified cylindrical deadlock designed for commercial and institutional doors requiring reliable security. Features a solid steel deadbolt with hardened, free-spinning steel pin insert and 1 inch throw. Ideal for offices, schools, healthcare facilities, and other applications demanding durable access control without complex installation.
Compatible with standard 1-3/4 inch doors; optional thicknesses and backsets available. Supplied with two nickel silver keys and non-handed operation for flexible mounting. Master keying and security options available for system-wide key control. Contact our authorized dealer experts at sales@edlocks.com or 1-877-207-6067 for specification verification, keying assistance, and professional guidance on your security project.
Specifications
- Grade 2 certified to ANSI/BHMA 156.5
- 1 inch deadbolt throw
- Solid steel deadbolt with hardened, free-spinning steel pin insert
- Standard door thickness: 1-3/4 inch (44mm); optional thicknesses available
- Standard backset: 2-3/4 inch (70mm); optional 2-3/8 inch (60mm)
- Front: brass or stainless steel, 2-1/4 inch x 1-1/8 inch; optional 1 inch width
- Strike: 2-3/4 inch x 1-1/8 inch standard; optional strikes and wrought boxes available
- Cylinder: 6-pin, L4 keyway, 0-bitted standard; security cylinder optional
- Handing: non-handed
- Includes two nickel silver keys
- Master keying and construction master keying available
- One-year limited warranty
