Description
The Falcon MA431L DG 605 is a heavy-duty mortise lock designed for commercial environments including offices, hospitals, and educational facilities. This dependable lock combines security with durability to withstand constant daily use without failure, making it ideal for retrofit projects that require quick re-keying capabilities.
The MA431L features an interchangeable core (SFIC-compatible) for easy maintenance and re-keying. It accommodates standard door thicknesses of 1-3/8" to 2-1/2" with a 2-3/4" backset. As an authorized Allegion dealer, E.D. Locks provides expert guidance on installation, keying options, and compatibility. Contact our specialists at sales@edlocks.com or 1-877-207-6067 for personalized support.
Specifications
- Brand: Falcon
- Model: MA431L DG 605
- Lock Type: Mortise
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4" only
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Hubs: Hardened steel
- Handing: Right hand standard; left hand optional, reversible in field
- Cylinders: Solid brass, 5/6/7-pin standard; 6/7-pin interchangeable core
- Keyways: G keyway (standard cylinder), A keyway (I/C cylinder)
- Latch Bolt: Two-piece stainless steel, 3/4" projection
- Deadbolt: 1" throw stainless steel with saw-resistant rollers
- Faceplates: 1-1/4" x 8" brass or stainless steel, adjustable for door bevel
- Strike: Brass or stainless steel, non-handed, ANSI A115.1 compliant
- Electrified Functions: 12 or 24 VDC available
- ANSI/BHMA: Series 1000
- UL Rating: 3 hour A label
