Description
The Falcon MA931B 606 is a heavy-duty mortise lock built for commercial environments like offices, hospitals, and educational facilities. It combines robust security with dependable performance under constant use, featuring an interchangeable core for quick re-keying and SFIC compatibility across manufacturers.
This lock accommodates standard door thickness from 1-3/8" to 2-1/2" and installs with a 2-3/4" backset. As an authorized Allegion dealer, E.D. Locks ensures you get genuine Falcon hardware with expert support for installation, keying, or electrified options. Contact sales@edlocks.com or 1-877-207-6067 for guidance on your project.
Specifications
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4"
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Hubs: Hardened steel
- Handing: Right hand standard; left hand optional, reversible in field
- Cylinders: Solid brass, 5, 6 or 7-pin standard; 6 or 7-pin interchangeable core
- Keyways: G keyway standard cylinder; A keyway interchangeable core
- Latch Bolt: Two-piece stainless steel, 3/4" projection
- Dead Bolt: 1" throw stainless steel with saw-resistant rollers
- Faceplates: 1-1/4" x 8" brass or stainless steel, adjustable for bevel
- Electrified Functions: 12 or 24 VDC available
- ANSI/BHMA: Series 1000 compliant
- UL Rating: 3 hour A label
