Description
The Falcon MA931B 630 is a heavy-duty mortise lock engineered for high-traffic commercial environments including offices, hospitals, and educational institutions. Built with cold-formed steel and hardened steel components, this ANSI/BHMA Series 1000 lock delivers reliable security and durability through constant daily use, backed by Allegion's reputation for quality.
The MA931B features an interchangeable core (SFIC-compatible) for quick re-keying without removing the lock body, and fits standard door thicknesses from 1-3/8" to 2-1/2" with a 2-3/4" backset. The lock includes a mechanical anti-friction latch bolt, 1" throw deadbolt with saw-resistant rollers, and bind-resistant through-bolted trim. Contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067 for expert guidance on handing, keyway selection, or electrified options.
Specifications
- Brand: Falcon
- Model: MA931B 630
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4"
- Case: Cold-formed steel, zinc dichromate plated, 0.090" thick
- Hubs: Hardened steel
- Latch Bolt: Two-piece stainless steel, 3/4" projection
- Deadbolt: 1" throw, stainless steel with saw-resistant rollers
- Faceplate: 1-1/4" x 8" brass or stainless steel, adjustable for door bevel
- Cylinder: Solid brass, 5, 6, or 7-pin available
- Interchangeable Core: Yes, 6 or 7-pin
- Standard Keyway: "G" (standard cylinder), "A" (I/C cylinder)
- Keys Furnished: Two nickel silver keys
- Handing: Right hand standard, left hand optional, reversible in field
- Electrified: Available in 12 or 24 VDC
- ANSI/BHMA: Meets ANSI/BHMA 156.13, Series 1000
- UL Rating: 3-hour A label
