Description
The Falcon MA931B 626 is a heavy-duty mortise lock engineered for commercial environments including offices, hospitals, and educational facilities. Its interchangeable core design enables quick re-keying without removing the lock, while the two-piece stainless steel latch and saw-resistant roller deadbolt provide dependable security through constant daily use.
This lock accommodates standard door thickness 1-3/8" to 2-1/2" with 2-3/4" backset and is SFIC-compatible for flexible keying across manufacturer products. Available in right or left hand, reversible in the field. As an authorized Allegion dealer, E.D. Locks offers expert guidance on handing, keying, and electrified options. Contact our team at sales@edlocks.com or 1-877-207-6067 for specification details and fast delivery.
Specifications
- Brand: Falcon
- Model: MA931B
- Finish: 626
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4" only
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Hubs: Hardened steel
- Handing: Right hand standard; left hand optional, reversible in field
- Cylinders: Solid brass, 5, 6, or 7-pin standard; 6 or 7-pin interchangeable core
- Standard Keyways: G keyway (standard cylinder), A keyway (IC cylinder)
- Latch Bolt: Two-piece stainless steel, 3/4" projection
- Deadbolt: 1" throw, stainless steel with saw-resistant rollers
- Faceplates: 1-1/4" x 8" brass or stainless steel, adjustable for bevel
- Strike: Brass or stainless steel, non-handed, meets ANSI A115.1
- Electrified: Available 12 or 24 VDC
- ANSI/BHMA: Meets 156.13, Series 1000
- UL Rating: 3 hour A label
