Description
The Yale 8800 Series mortise lock is engineered for commercial doors requiring ANSI/BHMA Grade 1 security and durability. This trim pack suits facilities, offices, and multi-tenant buildings where field-reversible installation, reinforced stainless steel deadbolts, and vandal-resistant hardware are non-negotiable. It solves the need for reliable, long-lasting access control on doors up to 3.25 inches thick.
Compatible with standard 1.75-inch doors and field-reversible for left or right handing, this lock installs quickly with adjustable bevel fronts and standard strike. The 625 finish is included. As an authorized Yale dealer, E.D. Locks provides expert guidance on keying options, compatibility with your door assembly, and warranty support. Contact sales@edlocks.com or call 1-877-207-6067 for free technical assistance.
Specifications
- ANSI/BHMA Certification: A156.13, Series 1000, Operational Grade 1
- Fire Rating: UL/cUL rated up to 3 hours
- Mechanism: Stainless steel
- Backset: 2-3/4 inch
- Latchbolt: 3/4 inch stainless steel throw
- Door Thickness: 1-3/4 inch standard, up to 3-1/4 inch available
- Front: Bevel, free-floating adjustment 0 to 1/8 inch in 2 inch
- Cylinders: Brass, 6-pin keyed-random, two keys standard
- Reversibility: Field reversible handing
- Strike: 1-1/4 inch curved lip for 1-3/4 inch door, reversible
- Finish: 625 (available in 17 finishes)
- Warranty: 10 year mechanical
