Description
The Yale 8860FL is a commercial-grade mortise lock built for high-security applications in offices, schools, hospitals, and institutional buildings. Its reinforced stainless steel deadbolt, ANSI/BHMA Grade 1 certification, and vandal-resistant trim deliver uncompromising strength and durability where security and reliability matter most.
Field-reversible handing and quick lever installation simplify setup on standard 1-3/4" doors and thicker applications. As an authorized Yale dealer, E.D. Locks offers expert guidance on finish selection, keying options, and compatibility. Contact our team at sales@edlocks.com or 1-877-207-6567 for specifications, bulk pricing, or custom configurations.
Specifications
- ANSI/BHMA Certified: Grade 1, A156.13 Series 1000
- Fire Rating: UL/cUL rated up to 3 hours
- Mechanism: Stainless steel
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door Thickness: 1-3/4" standard; up to 3-1/4" to order
- Cylinder: Brass, 6-pin keyed-random with 2 keys; 7-pin available
- Strike: 1-1/4" curved lip for 1-3/4" door; other lengths to order
- Handing: Field reversible
- Warranty: 10 years mechanical
