Description
The Yale 8862FL is a heavy-duty mortise lock built for commercial doors requiring ANSI/BHMA Grade 1 security and durability. Featuring a reinforced stainless steel deadbolt, vandal-resistant trim, and UL/cUL fire rating up to 3 hours, it solves security and code compliance needs in offices, retail, and institutional buildings.
Field reversible with standard 2-3/4" backset, 3/4" stainless steel latchbolt, and 1-3/4" door thickness, the 8862FL fits most commercial door frames. It comes keyed-random with two keys and a 10-year mechanical warranty. Contact E.D. Locks at sales@edlocks.com or 1-877-207-6067 for expert finish selection, handing verification, and free shipping on orders over $450.
Specifications
- ANSI/BHMA Certification: A156.13, Series 1000, Grade 1
- UL/cUL Fire Rating: Up to 3 hours
- Mechanism: Stainless steel
- Backset: 2-3/4 inches
- Latchbolt: 3/4 inch stainless steel throw
- Door Thickness: 1-3/4 inches standard, to 3-1/4 inches to order
- Cylinders: Brass, 6-pin keyed-random, two keys included; 7-pin available to order
- Reversibility: Field reversible handing
- Strike: 1-1/4 inch curved lip for 1-3/4 inch door standard; other lengths to special order
- Finishes: Available in 17 finishes
- Warranty: 10 years mechanical
