Description
The Yale 8847FL 626 is a heavy-duty mortise lock from the 8800 Series, built for commercial doors requiring ANSI/BHMA Grade 1 security and durability. It features a reinforced stainless steel deadbolt, vandal-resistant trim, and field-reversible handing for flexible installation on standard 1-3/4" doors.
This lock is UL/cUL fire-rated up to 3 hours and includes a 6-pin brass cylinder with two keys. Installation is straightforward with its quick lever handing and standard nonhanded strike. As an authorized Yale dealer, E.D. Locks provides expert guidance on keying, finish selection, and custom door thickness options. Contact sales@edlocks.com or call 1-877-207-6067 for assistance.
Specifications
- ANSI/BHMA Certification: A156.13, Series 1000, Operational Grade 1
- Fire Rating: UL/cUL up to 3 hours
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door Thickness: 1-3/4" standard (up to 3-1/4" available to order)
- Cylinder: 6-pin brass, keyed-random with two keys (7-pin available)
- Strike: 1-1/4" curved lip, reversible
- Field Reversible: Yes
- Warranty: 10 years mechanical
