Description
The Yale 8822FL 626 is a heavy-duty mortise lock built for commercial applications demanding uncompromising strength. Grade 1 certified, it features a reinforced stainless steel deadbolt, vandal-resistant trim, and a 3/4-inch throw latchbolt. Field-reversible handing and quick lever installation make it ideal for facilities managers and installers who need reliable, fast deployment across multiple door types.
This lock fits standard 1-3/4-inch doors and accommodates thicker doors to 3-1/4-inch with special order. It ships with a 6-pin keyed-random cylinder and two keys; 7-pin cylinders are available. As an authorized Yale dealer, E.D. Locks offers expert guidance on handing, keying, and door preparation. Contact sales@edlocks.com or 1-877-207-6067 for custom configurations and to ensure perfect fit.
Specifications
- Certification: ANSI/BHMA A156.13 Grade 1, UL/cUL fire rated to 3 hours
- Backset: 2-3/4 inches
- Latchbolt: 3/4-inch stainless steel throw
- Door Thickness: 1-3/4-inch standard, up to 3-1/4-inch to order
- Cylinder: Brass, 6-pin keyed-random, two keys included
- Strike: 1-1/4-inch curved lip for 1-3/4-inch doors, reversible
- Finish: Satin Chrome (17 finishes available)
- Warranty: 10 years mechanical
