Description
The Yale 8800 Series PBR8811-2FL mortise lock trim pack delivers commercial-grade security for high-traffic doors. Built for uncompromising strength and durability, this ANSI/BHMA Grade 1 certified lock features a reinforced stainless steel deadbolt, heavy-duty vandal-resistant trim, and UL/cUL fire rating up to 3 hours. Ideal for offices, hospitals, schools and other institutional applications requiring reliable access control.
This trim pack fits standard 1-3/4" doors and features a 2-3/4" backset with field-reversible handing for flexible installation. The stainless steel mechanism includes a 6-pin keyed-random cylinder with two keys, adjustable bevel front, and reversible strike. As an authorized Yale dealer, E.D. Locks provides expert guidance on finish selection, keying options, and installation. Contact our team at sales@edlocks.com or 1-877-207-6067 for compatibility questions and to explore our full mortise lock range.
Specifications
- Brand: Yale/Accentra
- Series: 8800 Series
- Certification: ANSI/BHMA A156.13 Grade 1
- Fire Rating: UL/cUL up to 3 hours
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door Thickness: 1-3/4" standard (up to 3-1/4" available)
- Mechanism: Stainless steel
- Cylinder: 6-pin brass, keyed-random with 2 keys (7-pin available)
- Front: Bevel front, free-floating 0 to 1/8" adjustment
- Strike: 1-1/4" curved lip, reversible
- Handing: Field reversible
- Finishes: 17 available
- Warranty: 10 years mechanical
