Description
The Yale 8800 Series mortise lock is a Grade 1 certified commercial lock designed for uncompromising strength and durability. Built with reinforced stainless steel deadbolts and heavy-duty, vandal-resistant trim, it solves security and longevity concerns for high-traffic commercial doors in offices, retail, and institutional settings.
This lock fits standard 1-3/4" doors and features field-reversible handing, a 3/4" stainless steel latchbolt, and a 6-pin keyed-random cylinder with two keys. UL/cUL fire-rated up to 3 hours and windstorm certified. For expert help selecting the right finish or keying configuration, contact E.D. Locks at sales@edlocks.com or 1-877-207-6067.
Specifications
- ANSI/BHMA A156.13, Series 1000, Operational Grade 1
- UL/cUL fire rated up to 3 hours
- Windstorm certified
- Mechanism: Stainless steel
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door Thickness: 1-3/4" standard, to 3-1/4" by special order
- Front: Bevel front, free-floating to adjust from flat to standard bevel of 1/8" in 2"
- Cylinder: Brass, 6-pin, keyed-random with two keys furnished; 7-pin available to order
- Strike: 1-1/4" curved lip for 1-3/4" door standard; other lip lengths by special order; all reversible
- Finishes: Available in 17 finishes
- Warranty: 10 year mechanical
