Description
The Yale 8800 Series mortise lock delivers ANSI/BHMA Grade 1 certified security for commercial doors. Featuring a reinforced stainless steel deadbolt and heavy-duty, vandal-resistant trim, this lock provides uncompromising strength and durability across demanding applications. Quick lever handing and a field-reversible latchbolt make installation straightforward.
This mortise lock fits standard 1-3/4" doors and accommodates thicker doors to 3-1/4" by special order. It is UL/cUL fire-rated up to 3 hours and backed by a 10-year mechanical warranty. As an authorized Yale dealer, E.D. Locks offers expert guidance on finish selection, keying, and installation. Contact sales@edlocks.com or call 1-877-207-6067 for personalized support.
Specifications
- ANSI/BHMA Certification: A156.13, Series 1000, Grade 1
- UL/cUL Fire Rating: Up to 3 hours
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door Thickness: 1-3/4" standard; up to 3-1/4" available
- Front: Bevel front, free-floating, adjustable flat to 1/8" standard bevel
- Cylinders: Brass, 6-pin keyed-random with two keys (7-pin available)
- Strike: 1-1/4" curved lip for 1-3/4" door; other lengths available
- Field Reversible: Yes
- Finishes: 17 available
- Warranty: 10 years mechanical
