Description
The Yale 8800 Series mortise lock trim pack is engineered for commercial doors demanding heavy-duty security and durability. Grade 1 certified, it features a reinforced stainless steel deadbolt, vandal-resistant trim, and field-reversible handing that simplifies installation on doors 1-3/4" to 3-1/4" thick. Ideal for offices, retail, and institutional settings.
This trim pack is compatible with Yale 8800 Series mortise locks and includes a standard 2-3/4" backset, 3/4" stainless steel latchbolt, and curved lip strike for 1-3/4" doors. All hardware is reversible for flexible installation. As an authorized Yale dealer, E.D. Locks provides expert support, finish selection guidance, and fast shipping. Contact sales@edlocks.com or call 1-877-207-6067 for questions or custom options.
Specifications
- ANSI/BHMA Certification: A156.13, Series 1000, Grade 1
- Fire Rating: UL/cUL up to 3 hours
- Mechanism: Stainless steel
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door Thickness: 1-3/4" standard; up to 3-1/4" to order
- Cylinders: 6-pin brass keyed-random with two keys; 7-pin available
- Strike: 1-1/4" curved lip for 1-3/4" door
- Finishes: 17 available
- Field Reversible: Yes
- Warranty: 10 year mechanical
