Description
The Yale 8800 Series mortise lock trim pack is a Grade 1 commercial-duty solution for interior and entrance doors requiring ANSI/BHMA certified security. Designed for institutional, hospitality, and multi-tenant buildings, it combines a reinforced stainless steel deadbolt with vandal-resistant trim to meet demanding security and durability standards.
This trim pack fits 1-3/4" standard doors and features field-reversible handing for flexible installation. The lock comes keyed-random with two keys; for keying assistance, compatibility questions, or finish selection from 17 available options, contact our team at sales@edlocks.com or 1-877-207-6067 for expert guidance as an authorized Yale dealer.
Specifications
- ANSI/BHMA Certification: A156.13, Series 1000, Operational Grade 1
- Fire Rating: UL/cUL rated up to 3 hours
- Mechanism: Stainless steel
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door Thickness: 1-3/4" standard (up to 3-1/4" available to order)
- Cylinders: Brass, 6-pin keyed-random with two keys (7-pin available to order)
- Strike: 1-1/4" curved lip for 1-3/4" door (reversible)
- Reversibility: Field reversible handing
- Finishes: 17 available options
- Warranty: 10 years mechanical
