Description
The Yale 8800 Series mortise lock is engineered for commercial doors requiring maximum security and durability. Featuring a reinforced stainless steel deadbolt and heavy-duty vandal-resistant trim, this ANSI/BHMA Grade 1 certified lock suits applications from office buildings to retail storefronts where strength and reliability are non-negotiable.
Field reversible handing and adjustable bevel front simplify installation on standard 1-3/4" doors. Specify backset, finish, and cylinder options to match your requirements. As an authorized Yale dealer, E.D. Locks offers expert guidance on keying, compatibility, and finish selection. Contact our sales team at 1-877-207-6067 or sales@edlocks.com for personalized assistance.
Specifications
- ANSI/BHMA Certification: A156.13, Series 1000, Grade 1
- UL/cUL Fire Rated: Up to 3 hours
- Windstorm Certified
- Mechanism: Stainless steel
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door Thickness: 1-3/4" standard (up to 3-1/4" available)
- Cylinders: Brass, 6-pin keyed-random with 2 keys standard; 7-pin available
- Fronts: Bevel front, free-floating, adjusts 0 to 1/8" in 2"
- Strikes: 1-1/4" curved lip for 1-3/4" doors standard
- Reversibility: Field reversible handing
- Finishes: 17 options available
- Warranty: 10 year mechanical
