Description
The Von Duprin QEL35ANL 3 313 RHR is a UL-listed rim exit device designed for single and double doors with mullion. Grade 1 ANSI A156.3-2014 certified, it provides reliable panic hardware for commercial and institutional buildings where code-compliant emergency egress is essential.
This non-handed rim device fits door widths 2'10" to 4' and mounts at 39 13/16" from finished floor. Compatible with wood and metal doors, it includes deadlocking latch bolt and required fasteners. As an authorized Von Duprin dealer, E.D. Locks offers expert guidance on finish selection, mullion configuration, and installation. Contact sales@edlocks.com or call 1-877-207-6067 for specification assistance.
Specifications
- Model: QEL35ANL 3 313 RHR
- Grade: ANSI A156.3-2014 Grade 1
- Device length: 2'4" to 3' (711mm to 914mm)
- Door width compatibility: 2'10" to 4' (864mm to 1219mm)
- Mounting height: 39 13/16" (1011mm) from finished floor
- Center case dimensions: 8 3/16" x 1 9/16" x 2 13/32" (208mm x 40mm x 62mm)
- Mechanism case dimensions: 2 1/4" x 2 1/4" (57mm x 57mm)
- Latch bolt throw: 3/4" (19mm), deadlocking
- Pushbar projection (neutral): 3 13/16" (97mm)
- Pushbar projection (depressed): 3 1/16" (78mm)
- Application: Single and double doors with mullion
- Handed: Non-handed (except with SS signal switch option)
- Includes: Sex bolts for 1 3/4" to 2 1/4" wood and metal doors
