Description
The Von Duprin RX3327AEO is a Grade 1 panic exit device designed for single and double doors in commercial and institutional settings. UL-listed and ANSI A156.3-2008 compliant, it features a grooved mechanism case, deadlocking anti-friction top and bottom bolts, and a surface vertical rod design ideal for facilities requiring reliable emergency egress.
This exit-only device (EO function) accommodates standard 7-foot doors with adjustable rod lengths and fasteners for wood and metal applications. For proper installation on your specific door size and configuration, or to verify compatibility with your existing hardware, contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067 for expert guidance.
Specifications
- Model: RX3327AEO 4 US28
- Grade: ANSI A156.3-2008 Grade 1
- Finish: US28 (Satin Aluminum)
- Device Centerline: 39 13/16" (1006 mm) from finished floor
- Center Case Dimensions: 8 13/16" x 2 13/32" x 1 9/16" (208 mm x 62 mm x 40 mm)
- Mechanism Case Dimensions: 2 1/4" x 2 1/4" (57 mm x 57 mm)
- Pushbar Neutral Projection: 3 13/16" (97 mm)
- Pushbar Depressed Projection: 3 1/16" (78 mm)
- Latch Bolt: Deadlocking anti-friction, 5/8" (16 mm) throw
- Door Undercut: 1/4" (7 mm)
- Top & Bottom Latch Dimensions: 4 1/2" x 2 1/8" x 1 1/2" (114 mm x 54 mm x 38 mm)
- Vertical Rods: 1/2" square tubing, standard 7' (2134 mm) door capacity
- Top Rod Length: 34 15/16" (887 mm)
- Bottom Rod Length: 31 1/4" (794 mm)
- Extension Rods: Available 1' (205 mm) or 3' (914 mm) for doors over 7'
- Door Size Range: 2'8" to 4' (813 mm to 1219 mm)
- Function: Exit Only (EO)
