Description
The Von Duprin RXEL35AEO 3 is a UL-listed rim exit device designed for single and double doors with mullions. Built to ANSI A156.3-2014 Grade 1 standards, this panic hardware solution meets life-safety codes for commercial buildings, schools, and public facilities requiring reliable emergency egress.
Compatible with doors 28" to 48" wide, the device installs on the interior face of wood and metal doors. As an authorized Von Duprin dealer, E.D. Locks provides expert sizing assistance, finish selection, and keying support. Contact our sales team at sales@edlocks.com or 1-877-207-6067 for specification guidance and fast shipping on orders over $450.
Specifications
- Device lengths: 2'4" to 3' (711mm to 914mm)
- Door size: 2'10" to 4' (864mm to 1219mm)
- Device centerline from finished floor: 39 13/16" (1011mm) or 39 11/16" (1008mm) with mullion
- Center case dimensions: 8 3/16" x 1 9/16" x 2 13/32" (208mm x 40mm x 62mm)
- Mechanism case dimensions: 2 1/4" x 2 1/4" (57mm x 57mm)
- Pushbar neutral projection: 3 13/16" (97mm)
- Pushbar depressed projection: 3 1/16" (78mm)
- Latch bolt: Deadlocking, 3/4" (19mm) throw
- Grade: ANSI A156.3-2014 Grade 1
- UL listed for panic exit hardware
- Non-handed except with SS (signal switch) option
- Includes #425 SNB fasteners (wood/metal doors) and #325 SNB (exit-only configuration)
