Description
The Falcon T Series T351PD is an extra heavy-duty Grade 1 cylindrical lock engineered for high-traffic and heavy-abuse institutional environments. It exceeds ANSI/BHMA Grade 1 testing requirements with a compression spring design and solid brass construction, making it ideal for schools, offices, and facilities demanding durability and security at an economical price point.
This lock accepts standard manufacturer cylinders and features easily removable cylinders for quick re-keying and retrofitting. Preassembled with brass roses and pressure-cast levers, installation is straightforward. As an authorized Falcon dealer, E.D. Locks provides expert configuration assistance and free shipping on orders over $450. Contact sales@edlocks.com or call 1-877-207-6067 for handing, keying, and specification guidance.
Specifications
- Grade: ANSI/BHMA Grade 1
- Door Thickness: 1-3/4" to 2-1/8" standard (thin door adapter A30775-000-00 available)
- Backset: 2-3/4" standard (2-3/8" available; 5" backset link A22161-005-10 available)
- Cylinder: 6-pin drilled, pinned in 5 (6-pin or 7-pin available; interchangeable core SFIC/large format options available)
- Keyway: G-keyway standard (A-keyway on I/C cores; optional keyways available)
- Bolt Projection: 9/16" standard (3/4" projection with 2-3/4" backset also available)
- Latch Faceplate: 2-1/4" x 1-1/8" with square corners, UL listed
- Strike: 4-7/8" x 1-1/4" ANSI strike with curved lip
- Construction: Brass or cold-formed steel mechanism, zinc-plated and dichromated; stainless steel springs
- Trim: Wrought brass or bronze roses over pressure-cast inserts; pressure-cast solid levers
- Handing: Non-handed
- Keys: Two nickel silver keys furnished standard
