Description
The Falcon T501BD A 626 is an extra heavy-duty Grade 1 cylindrical lock engineered for high-traffic and heavy-abuse commercial and institutional applications. Its compression spring design exceeds ANSI/BHMA Grade 1 testing requirements, delivering reliable security and durability at an excellent value for demanding environments.
This lock accepts any manufacturer's cylinder and features removable cylinder assemblies for quick, easy re-keying and simple retrofitting. Standard door thickness accommodation is 1-3/4" to 2-1/8", with adapter kits available for thinner doors. As an authorized Falcon dealer, E.D. Locks provides expert installation guidance and compatibility support. Contact our team at sales@edlocks.com or 1-877-207-6067 for questions on keying options, backset configurations, or trim selections.
Specifications
- Grade: ANSI/BHMA Grade 1
- Door Thickness: 1-3/4" to 2-1/8" standard (adapter kit A30775-000-00 available for thinner doors)
- Backset: 2-3/4" standard, 2-3/8" available, 5" via link A22161-005-10
- Bolt Projection: 9/16" standard, 3/4" available
- Handing: Non-handed
- Cylinders: 6-pin chambers pinned in 5 (6-chamber or 7-pin available)
- Cylinder Material: Solid brass housing and plugs
- Keyway: G keyway standard (A keyway for interchangeable core)
- Mechanism: Brass or cold-formed steel parts, zinc plated and dichromated; stainless steel springs
- Roses: Heavy wrought brass or bronze
- Latch Faceplate: 2-1/4" x 1-1/8" with square corners standard
- Strike: 4-7/8" x 1-1/4" ANSI strike with curved lip
- Keys: Two nickel silver keys furnished standard
- Interchangeable Core: Small format (SFIC) and large format options available
